Name: QVidium QVDec™ MPEG-4 AVC / MPEG-2 IP Decoder
Availability: InStock

QVidium’s QVDEC decoder is part of a reliable, high-performance solution for the decoding and transport of SD and HD video/audio signals for broadcast applications. Advanced H.264 High Profile compression, coupled with QVidium’s patented ARQ Video Transport and Error correction, helps to maintain broadcast quality video distribution over nearly any IP network, including wireless networks and the Internet.

QVidium Patented feed-back based error correction (ARQ)
USB for playing back video files
4 channel audio output on SDI or analog audio
Simultaneous HDMI, SDI and Composite output
7 VDC to 18VDC Power Input directly or through AC Power Adapter.
AC3 audio pass through on SDI and S/PDIF output
Powerful HD to SD down/up scaler and frame rate converter
DVBCSA Decryption
Web Streaming w/SDI output: WEB Cams, YouTube, CDNs
Full Closed Captioning Support: CEA-608, CEA-708, VANC & Line 21

SKU: N/A Category: Encoders/Decoders

Description

The QVDEC is part of the QVidium® professional line of advanced video codecs; a line of compact, powerful and cost-effective products designed for real-time encoding, and decoding for Content Gathering, Monitoring, and Distribution of broadcast quality video over IP networks.

QVidium’s advanced video transport couples broadcast and networking standards with patented error correction to take advantage of the inherent flexibility of IP and the Internet, providing broadcasters an efficient, affordable and scalable solution for professional quality video distribution quality over nearly any IP network.

The QVDEC provides H.264 High Profile video decompression, up to 1080p50/60, along with support for up to 4 audio channels, multicasting, and multi-unicasting to allow cost-effective audio/video broadcast and IPTV solutions.

Key Features

QVidium Patented feed-back based error correction (ARQ)
USB for playing back video files
4 channel audio output on SDI or analog audio
Simultaneous HDMI, SDI and Composite output
7 VDC to 18VDC Power Input directly or through AC Power Adapter.
AC3 audio pass through on SDI and S/PDIF output
Powerful HD to SD down/up scaler and frame rate converter
DVBCSA Decryption
Web Streaming w/SDI output: WEB Cams, YouTube, CDNs
Full Closed Captioning Support: CEA-608, CEA-708, VANC & Line 21

Major Benefits

MPEG-4 AVC Video: MPEG-4 AVC 4:2:0 video decoding selectable up to 25 Mbps transport-stream bit rates
Incorporates QVidium’s patented feed-back based error correction (ARQ): QVidium’s ARQ provides the most reliable video transport over any IP network, including wireless and unconditioned IP networks.
MPEG-2 Video: MPEG-2 4:2:0 video decoding selectable up to 25 Mbps transport-stream bit rates
Simple interconnect: Gigabit Ethernet interface allows simple interconnection to most network equipment for management.
Easy to Manage:Easy to manage through web-based user management and SNMP Traps.
